Working principle：
Working principle: the film, PE bag, carton, cards and other paste was folded stack (a) placed on the paging device, paging device automatically posted material a a separate transport to the conveyor belt, conveyor belt by vacuum adsorption the adsorption of products on the transporting belt forward line, optical fiber sensor to detect the product after, the signal is transmitted to labeling control system, in the default position control system sends a label and is attached in the product to be the label position, the product flows through the coating roller, label is pasted, a label paste attached to the action.
Work process: manual release products - > product automatically separated and delivered - > product testing - Product Labeling - collection has been labeling products - > remove products.
Scope of application:
Applicable label: self adhesive label, pressure sensitive adhesive film, electronic supervision code, bar code, etc..
Apply to products: requirements in the plane, large curved surface attached to the label or film products.
Application: PE bags, paper boxes, paper cards, lottery, plastic, ceramics etc..
Product features:
Card (film) stability: the use of advanced friction technology sub card, card sorting rate is much higher than the general sub card mechanism;
Card (film) for high speed labeling kit with regulatory code, stable speed can reach 200 per minute;
Wide scope of application: can meet all kinds of cards, films, paper, non folding carton labeling;
Labeling: the top roller pressure on the stability of the workpiece, smooth transmission, warping, ensure the accuracy of labeling;
Labeling of high precision: servo motor drive send, send accurate; standard with bypass corrective mechanism design to ensure label traction process is not about offset; the industry's most advanced diamond wheel with double gagun technology is applied to label the traction mechanism, traction label does not slip, to ensure that a standard robust and accurate;
High stability of the machine: Germany's Siemens PLC Taiwan vinylon touch screen and the AB inverter German labor to label eye is composed of advanced electronic control system, support equipment 7 * 24 hours of operation.
No artificial real-time supervision: before the label is used up, the machine automatically sound and light to remind the operator to replace the label roll, to avoid the lack of labels stop delay production;
For standard operation is simple: stick header agencies give full consideration to the design of a mark containing the convenience, leaving enough space for easy manual operation, saving a large amount of loaded label time to improve production efficiency;
Linear flow is sent to standard design: label in transport process in the wrap angle and linear flow design, to avoid the hard tag, label label glue not sticky or cold weather cooling conditions in the pre bid was stripped in the send process, reduce the production risk and improve the production efficiency;
Mark never slip by emery send round with elastic gagun sent to standard, strong, never slip, is marked by more accurate;
Intelligent control: automatic calculation of label length, change the label machine automatically adjusting the parameters; conveyor belt and guiding entrainment synchronous control, a button can yield adjustment; automatic photoelectric tracking, with no labeling, no standard automatic calibration and label automatic detection function, prevent leakage and label waste paste;
Production of humanized management: with automatic shutdown, production count, power-saving features (set time in production, the equipment will automatically go to the power saving standby state), production number set prompt function, convenient production and management;
When you switch to a different product is simple: in the production process of switching different types of bottles directly click the touch screen in the corresponding configuration parameters, you can adjust the position of the fence; artificial debugging equipment, man-machine interface with didactic function, parameter modification is simple and clear, the various functions cut simply change;
With the fault alarm function, the lack of label automatic reminder, production counting function, power saving function, production number set prompt function, parameter setting protection function.
Optional features and components:
The thermal code printer / function;
Automatic material feeding function (combined with product consideration);
Automatic feeding function (combined with product consideration);
The increase in labeling device;
The other function (customized according to customer requirements).
Technical parameter:
The following is the standard type of technical parameters, special requirements and other functions, can be customized
Applicable label length: 6mm ~ 250mm;
Applicable product size (length * width * height / thickness): long: 40mm ~ 280mm; width: 40mm ~ 200mm; high: 0.1mm ~ 3mm;
Application of standard coil diameter: 280mm diameter; diameter: diameter of 76mm for target volume;
Labeling accuracy: 2mm 1~ (depending on the paste;
Speed: 30m/min;
Labeling speed: servo: 50 ~ 200pcs/min;
Conveying speed: speed control motor: 5 ~ 30m/min;
Weight: about 180kg;
Frequency: 50HZ; voltage: 220V/50Hz; power: 1200W;
Equipment outline dimension (mm) (L * w * h): 1500mm * 700mm * 2200mm.
