Performance characteristics
This machine used in Europe and the United States advanced spiral wind technology, good efficiency of contraction, electronic speed control motor, speed adjustment range, conveying chain wheel with white resistant casing temperature, not hot bad shrink film and packaging, completely solve the bottom difficult to shrink bundle disturbance.
Principle and scope of use of shrinking machine
Shrink packaging is currently on the market more advanced method of packaging, it is the use of shrink film package or packages in the product out, and heating the contraction and wrapped tight products or packages, fully display the item's appearance and improve the sale of products, to increase the aesthetics and values. At the same time, the packing of the goods can be sealed, moisture, anti pollution, so this product is widely used in various kinds of small and medium goods packaging.
Technical parameter:
Machine model
FY-4020L heat shrink packaging machine
Working power supply
380V
overall length
1500 mm
Heat storage silo
1000 mm
Inlet size
400 x 200 mm
Rated power
9KW
Conveyor belt speed
0-12M/ minutes
temperature
Room temperature -250
Fan speed
0-2800 rev / min
Heating method
Quartz tube
Packaging
POF, PVC
Conveyer belt
Sprocket
Mechanical Dimensions
1500x550x1300mm
Mechanical weight
80kg
